OCTOBER 2013 CORPORATE PRESENTATION – Ivanhoe Energy, Inc.

Ivanhoe Energy, Inc. · Oct 10, 2013 · 17 slides

Investor presentation from the Shale Experts oil & gas presentation and slide database. Every page is imaged and its text indexed for search across operators, plays, basins and time.

Slides

  1. OCTOBER 2013 CORPORATE PRESENTATION – Ivanhoe Energy, Inc. – slide 1
    A New Look at Heavy Oil By: Carlos A. Cabrera Date: October 23, 2013 2013 Ivanhoe Energy All rights reserved
  2. OCTOBER 2013 CORPORATE PRESENTATION – Ivanhoe Energy, Inc. – slide 2
    Crude Oil Demand & Supply Future demand to be met by heavy oil production Crude Oil demand is estimated to grow byForecasted 15% in the next 10 Growth Crude Oil years. Heavy Oil can fulfill approximately 10% of that demand Demand 85…
  3. OCTOBER 2013 CORPORATE PRESENTATION – Ivanhoe Energy, Inc. – slide 3
    Industry Efforts to Develop Heavy Oil to Date Using heat for transportation and production Upgrading in the field with high complexity and high cost upgraders Diluting the bitumen and shipping to refineries Ivanhoe Energy…
  4. OCTOBER 2013 CORPORATE PRESENTATION – Ivanhoe Energy, Inc. – slide 4
    Headwinds to Heavy Oil Development: Production is energy intensive High viscosity, low API limits transportability High capital requirements challenge economics Tight oil growth in North America Residual oil lowers value of refined…
  5. OCTOBER 2013 CORPORATE PRESENTATION – Ivanhoe Energy, Inc. – slide 5
    Tailwinds Supporting Heavy Oil Development: Sub-surface and surface extraction improvements Constructability and modularization Pipeline de-bottlenecking (no need to ship diluent) Energy efficiency Synthetic crude is compatible…
  6. OCTOBER 2013 CORPORATE PRESENTATION – Ivanhoe Energy, Inc. – slide 6
    Innovations in Heavy Oil Resource Development Sub-surface Advances in drilling techniques Combined technologies lead near-term advances in heavy oil recovery processes Innovations in thermal Enhanced Oil Recovery (EOR)…
  7. OCTOBER 2013 CORPORATE PRESENTATION – Ivanhoe Energy, Inc. – slide 7
    Innovations in Heavy Oil Resource Development Sub surface and surface technology has advanced incrementally; more progress is required Surface Facilities Efficient supply and use of energy Improvements in the effectiveness and…
  8. OCTOBER 2013 CORPORATE PRESENTATION – Ivanhoe Energy, Inc. – slide 8
    A Paradigm Shift for Upgrading Heavy Oil Upgrading Today Upgrading Tomorrow Ivanhoe Energy Presentation 9
  9. OCTOBER 2013 CORPORATE PRESENTATION – Ivanhoe Energy, Inc. – slide 9
    HTL vs. Traditional Upgrader Capital Intensities (30,000 BPD) The Capital intensity of HTL is approximately 40% of the 90 current delayed coker technology in use today 80 70 80 60 1,000 / BPD 50 40 52 30 43 20 10 18…
  10. OCTOBER 2013 CORPORATE PRESENTATION – Ivanhoe Energy, Inc. – slide 10
    HTL vs. Traditional Upgrader Space Requirements (30,000 BPD) The 12 Plot space requirements of HTL is approximately 31% of the current delayed coker technology in use today 10 HECTARES (10,000 m2) 8 10.3 9.3 6 8.2 4…
  11. OCTOBER 2013 CORPORATE PRESENTATION – Ivanhoe Energy, Inc. – slide 11
    Steam Equivalent Energy Required for Extraction HTL provides all, or a majority of, the energy required for 7 heavy oil production 6 5 Barrels Steam per 4 Barrel Production 3 2 Energy provided by HTL per barrel of…
  12. OCTOBER 2013 CORPORATE PRESENTATION – Ivanhoe Energy, Inc. – slide 12
    Comparing HTL SCO quality against other crudes Partial upgrading provides SCO that is higher value and welcomed by refineries Decreasing Market Value 102/bbl 100/bbl 94-98/bbl 95/bbl 86/bbl 72/bbl 100 Crude Oil Fractions, volume…
  13. OCTOBER 2013 CORPORATE PRESENTATION – Ivanhoe Energy, Inc. – slide 13
    Net Return per barrel: HTL versus traditional supply chain A Range of 10 to 14 per barrel of additional netback is realizable by HTL 84.00 (13.15) (11.50) Diluent * Traditional Shipping Value Loss (15.00) (6.15) Cost (16/bbl…
  14. OCTOBER 2013 CORPORATE PRESENTATION – Ivanhoe Energy, Inc. – slide 14
    Commercializing HTL: Business Models Field Integrated Model eg. Tamarack, Block 20 Midstream Model Projects in development Ivanhoe Energy Presentation 15
  15. OCTOBER 2013 CORPORATE PRESENTATION – Ivanhoe Energy, Inc. – slide 15
    Ivanhoe Energy: Undervalued With Upside Potential Ivanhoe Energy is an international petroleum company differentiated by its heavy oil upgrading process: HTLTM. It also has core geologic assets in Canada and Ecuador. Tamarack, Canada…
  16. OCTOBER 2013 CORPORATE PRESENTATION – Ivanhoe Energy, Inc. – slide 16
    The Future is Bright for Ivanhoe Energy Meeting the supply gap of crude oil demands fresh, innovative approaches to improve efficiencies in production, transportation and conversion. Ivanhoe Energy Presentation 17 Ivanhoe Energy…
  17. OCTOBER 2013 CORPORATE PRESENTATION – Ivanhoe Energy, Inc. – slide 17
    Thank you Questions P +1 403 261 1700 F +1 403 261 2698 E infoivanhoeenergy.com ivanhoeenergy.com Ivanhoe Energy Presentation 18
