Technip Building Solutions for the Energy Industry Photos: Technip Photo library, Jean Gaumy/Magnum, Harry Gruyaert/Magnum, Patrick Zachmann/Magnum, all rights reserved Tim Crome, Sales and Business Development Manager Technip…
Ambition The Reference Company for Safety High Focus on Safety and Education - Initiatives: PULSE Programme Technip University Technip to become The Reference Company for Safety in our Sector PULSE Programme: 3 Annual Safety…
Contents I. Technip Norway and Market II. Technips roles in Norway III. Subsea Assets and Technology IV. Pipeline Repair System Facility 3
I. Technip Norway and Market I. 4
Norway is part of our North Sea Canada Region St. Johns Aberdeen Oslo Regional Headquarters Satellite operating centers Spoolbase Manufacturing plant (umbilical) 5
Presence in Norway Operating in Norway since 1985 National Headquarters Established offices in Norway Satellite operating centers since 1988 Spoolbase 2010 Employees Total Group: 23,000 Technip Norway 1.5% Orkanger…
Technip Norge 7
Ever increasing Client Base A few years back Today 8
II. Technips roles in Norway 9
Diversified Activities Engineering, Procurement, Construction and Installation (EPCI) Projects Tie-Backs Subsea Construction Flexible Riser and Flowline Supply IRM* & Diving PRS** Base Offshore * IRM: Inspection, Repair…
EPCI Project - Goliat SURF for ENI Goliat: ENI Norge First Norwegian oil field development north of the Arctic Circle Differentiating Assets: Deep Energy will provide quick access to this remote area in the Barents Sea.…
Tie-Back - Marulk for Statoil Subsea tie-backs to existing platforms getting longer Increasing flow insurance challenges Better insulation required to ensure thermal performance Traditional wet coatings no longer sufficient…
Largest and most sophisticated Diving Support / Construction Vessel in the world Skandi Arctic (DSV) Start of operations: 2009 Length: 157 meters Speed: 16 knot Accommodation: 140 people Class 3 dynamic positioning system 3…
Major Flexible Pipe References in Norway Alvheim Dynamic riser configuration First smooth bore for gas export riser: Aasgard Aasgard project Balder COD Fram Vest & st Garn Vest Gullfaks Heidrun KristinNjord Norne Ringhorne…
IRM* and Diving Activities Exclusive diving frame agreement with Statoil Umbilical Repairs Kvitebjrn Pipeline Repair Langeled Tie-Ins (PRS) Ormen Lange Hot Taps Light Diving Air diving from dedicated Light Diving Craft…
Norwegian waters offer Offshore opportunities Technip has extensive experience and knowledge on platforms and topsides Growing study activity in Norway Developing solutions for harsh arctic environments Identifying partners…
III. Subsea Assets and Technology 17
Orkanger Spoolbase 18
State-of-the-art fleet Pipelay vessels 3 units Deep Blue Apache II Deep Energy Heavy Construction Vessels (HCV) 5 units Deep Pioneer Deep Constructor Sunrise 2000 Skandi Vitoria Skandi Niteroi 2 major vessel Diving…
Investment in Key Assets for Norway Apache II Deep Energy Orkanger New rigid pipe reelay New deepwater rigid / Upgrade of facilities vessel using proven umbilical / flexible lay ongoing equipment vessel Preparation for…
Unmatched Vertically Integrated Business to Optimize Design & Execution 1 R&D Design & Project Management 2 Risers Optimized solutions Oslo Pipeline Welding Custom engineering Stavanger Installation methods Dedicated local…
New Technological Solutions for the challenging products and longer tie-backs Flexible Development Flow assurance Smoothbore Heated and monitored Heated Rigid Gas Export Riser Flexible Pipes Pipe-in-Pipe First smooth bore for…
Hot Taps Hot Tapping Process of safely drilling a hole in a live pipeline Enables connections to existing pipelines without disturbing operation Opens possibility for tie-backs to existing infrastructure Diver (Tampen Link /…
Pipeline Repair System IV. (PRS) Facility 24
Haugesund PRS Facility 25
Norwegian Gas Exports Gassco is responsible for transporting the gas to Europe Total volume of gas delivered was 96.6 bn scm in 2009 Value - US15 billion Based on Henry Hub spot price Includes 1/3 of UK needs 26
PRS Function Rapid response for pipeline repair Ensure regularity of gas supplies Founded 1987 Unique pool of emergency repair equipment Equipment varies with pipe size and water depth Owned by a group of NCS oil & gas pipeline…
Technip and PRS Technip Norge AS was awarded PRS contract in January 1, 2007, with responsibility to: Preserve a state of readiness for emergency call-out, including availability of trained personnel Maintain and store the…
Equipment you will see today Morgrip couplings Pipeline connection without welding Coupling Installation Frame Manoeuver Morgrip into position on pipeline ends
Equipment you will see today Hot Tap Machine Only machine in the world able to perform a hot tap into a live pipeline beyond diver depths Used to connect the third template on Ormen Lange in 850meters of water
Equipment you will see today H-frames Lift and align pipelines for connection Welding Habitats Provide the environment for diver welding of pipelines 31
Equipment you will see today Welding Machines Performs butt weld, connecting two sections of pipe together Concrete removal and cutting machine To remove concrete pipeline coatings and cut the pipe ends using high pressure…
Remote Pipeline Repair System Welding 1 km below the sea surface Development Work PRS welding system for use beyond diver depth: Remote Orbital Welding Tool (ROWT) Handling systems for ROWT Remote hot tap tee installation and…
Conclusion Key Messages Technips unmatched EPCI capability Excellent solutions for subsea tie-backs Vertically integrated subsea business High tech assets Thorough competence in: Engineering Project management IMR, including the…
