NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil

Madagascar Oil · Nov 26, 2013 · 33 slides

Investor presentation from the Shale Experts oil & gas presentation and slide database. Every page is imaged and its text indexed for search across operators, plays, basins and time.

Slides

  1. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 1
    MADAGASCAR OIL LIMITED Steaming Towards First Oil Presentation to Africa Oil Week 26th November 2013
  2. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 2
    Madagascar Oil License Position and Tsimiroro History
  3. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 3
    Madagascar Oil Limited Licenses in Madagascar Madagascar Oil License position License Block Summaries Block 3104 Tsimiroro Concession Block 3105 Manambolo Concession Block 3106 Morondava Concession Block 3107 Manandaza…
  4. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 4
    Madagascar Oil Limited Tsimiroro Discovered Field in Block 3104 3104 and 3102 Block Summaries Block 3104 - Tsimiroro Concession Operator: Madagascar Oil 100% Area: 6666.88 sq Km Bemolanga Block 3102 - Bemolanga Concession…
  5. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 5
    Madagascar Oil Limited Block Tsimiroro Field History Timeline Tsimiroro Field history - a +100 Year Timeline 5
  6. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 6
    Madagascar Oil Limited Block 3104 Tsimiroro Tsimiroro Block 3104 The Tsimiroro Field is a giant heavy oil reservoir 60 Km North South, 5-10 Km East West Stock Tank Oil Originally In Place Netherland Sewell 2011 Contingent Resources…
  7. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 7
    Tsimiroro Steam Flood Pilot Year to Date 2013 Performance
  8. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 8
    Madagascar Oil Limited Block 3104 Tsimiroro Steam Flood Pilot The Tsimiroro Steam Flood Pilot Conceived after 2008 CSS Huff and Puff success Designed as a test of the thermal recovery method successfully applied in California,…
  9. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 9
    Tsimiroro Steam Flood Pilot 2013 Commissioning Milestones MILESTONES 2013 Construction Completion - a significant achievement 9
  10. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 10
    Tsimiroro Steam Flood Pilot 2013 Commissioning Milestones Steam Generation and Distribution Facilities 10
  11. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 11
    Tsimiroro Steam Flood Pilot 2013 Commissioning Milestones Production, Separation and Oil Storage Facilities 11
  12. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 12
    Tsimiroro Steam Flood Pilot Steam Flood Operations Steam Flood Pilot wells The Steam Flood Pilot Area is a 5 spot pattern with 16 production and 9 injection wells 12
  13. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 13
    Tsimiroro Steam Flood Pilot Steam Flood Operations Typical Well Wireline Log The Amboloando sandstone is encountered at 110-120 metres depth - -70-80 metres thick 13
  14. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 14
    Tsimiroro Steam Flood Pilot Good Uniform Reservoir Quality in the SFP Area A Log Cross Section shows the oil column and reservoir continuity across the SFP Area SW PSF-05 OBSF-01 PSF-06 ISF-05A OBSF-02 ISF-09 OBSF-03 NE Amboloando…
  15. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 15
    Tsimiroro Steam Flood Pilot Steam Flood Operations - Steam Injection Profile Tsimororo Steam Flood Pilot Steam Injection Performance April to November 2013 2,000 Steam Injection Rates have built up to 1400 BWEPD 1,500 Steam…
  16. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 16
    Tsimiroro Steam Flood Pilot Steam Flood Operations Oil Production Profile Tsimororo Steam Flood Pilot Oil Production Performance April to November 2013 400 Oil Production Rates have built up to 200 - 300 BOPD 300 Oil…
  17. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 17
    Tsimiroro Steam Flood Pilot CSS (Huff and Puff) Operations Initial wells are into their 4th Huff and Puff Cycle eg PSF-3 Tsimororo Steam Flood Pilot - Well Perfomance PSF-3 April to November 2013 300 Injection Production Injection…
  18. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 18
    Tsimiroro Steam Flood Pilot Temperature Observation Well Monitoring Temperature Observation wells allow tracking of the thermal response Temperature [C] 27.7 32.7 37.7 42.7 0 Temperature Observation Well OBS-01 Response…
  19. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 19
    Tsimiroro Steam Flood Pilot Tsimiroro Crude Oil Tsimiroro Oil - sweet, heavy crude Tsimiroro Crude API 15 Low Sulphur 19
  20. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 20
    Tsimiroro Steam Flood Pilot Steam Flood Pilot Crew Tsimiroro Steam Flood Pilot crew celebrating 2 million manhours without a LTI 20
  21. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 21
    Madagascar Oil Community Projects Working with local villages to provide health, education and sanitation improvements Health Clinic Handover in Ankisatra Water well completion in Beravina Income Generation Nursery Plantation…
  22. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 22
    Tsimiroro Full Field Development Plan
  23. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 23
    Tsimiroro Development Planning Development Plan - Document The Development Plan will integrate all threads of technical, commercial and non-technical (Stakeholder) issues Geological & Geophysical Reservoir Exploration Drilling…
  24. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 24
    Tsimiroro Development Planning Tsimiroro Field Development Phases Proposed phased Field Development Plan Steam Flood Pilot Phase 1 Phase 2 Phase 3, 4, 5 The phases will encompass ever larger areas of the field and will include…
  25. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 25
    Tsimiroro Development Planning Notional Phased Development Phases - Key Characteristics Steam Flood Phase 1 Phase 2 Phases 3, 4, 5 Pilot STOOIP 3 MMb 50-100 MMb 300-500 MMb 1,700 MMb Recovery Cyclic to Steam Cyclic to Steam Flood…
  26. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 26
    Tsimiroro Development Planning Phase 1 Development Processing Facility The Steam Flood Pilot Facilities can be used during the Phase 1 Development 26
  27. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 27
    Tsimiroro Development Planning Road sections East and West of Tsimiroro SFP may require upgrades Annual General Meeting, September26 27 2013
  28. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 28
    Tsimiroro Field Development Planning Phase One Markets Local & International Annual General Meeting, September26 28 2013
  29. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 29
    Madagascar Oil Exploration Licenses 3105 Manambolo 3106 Morondava 3107 Manandaza
  30. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 30
    Madagascar Oil Exploration Licences Blocks 3105, 3106, 3107 Block Summaries Block 3105 - Manambolo Concession Operator: Madagascar Oil 100% Legacy Well Control - 6 Wells 1971-1993 Area: 3980 sq km (0.980 MM Ac) Block 3106 -…
  31. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 31
    Madagascar Oil Exploration Licences Blocks 3105, 3106, 3107 2013 WORK PROGRAMME Database QC and correction and project build : Regional geology, structural and stratigraphic framework AGG interpretation Seismic Interpretation,…
  32. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 32
    Madagascar Oil Tsimiroro Field Steaming Towards First Oil Misotra Tompoko Veloma
  33. NOVEMBER 2013 CORPORATE PRESENTATION – Madagascar Oil – slide 33
    Madagascar Oil Copyright - All rights reserved
