IM 5 DRILLING UPDATE – Bowleven Plc

Bowleven Plc · Jan 30, 2013 · 4 slides

Investor presentation from the Shale Experts oil & gas presentation and slide database. Every page is imaged and its text indexed for search across operators, plays, basins and time.

Slides

  1. IM 5 DRILLING UPDATE – Bowleven Plc – slide 1
    IM-5 Drilling Update 30th January 2013 30th JANUARY 2013 IM-5 Drilling Update 1
  2. IM 5 DRILLING UPDATE – Bowleven Plc – slide 2
    IM-5 Well Pre-drill targets and results to date IM-3 IM-5 (Currently drilling) Upper Isongo Isongo volcanics Upper Isongo (Sands below GWC). 32m (net) encountered and found wet as prognosed. Intra Isongo Intra Isongo…
  3. IM 5 DRILLING UPDATE – Bowleven Plc – slide 3
    Seismic Correlation Panel Tying IM Wells IM-4 IM-2 IM-3 IM-5 Upper Isongo Upper Isongo Intra Isongo Intra Isongo Provisional estimated net 3m net pay 52-56m Areally extensive Intra pay. Below Isongo amplitude response…
  4. IM 5 DRILLING UPDATE – Bowleven Plc – slide 4
    Top Intra Isongo Depth Contours Overlaid on Intra Isongo Amplitude Response Orientation of Fig.2 Green to Orange: Intra Isongo reservoir present above seismic resolution (i.e. implies gross reservoir thickness greater than…
