Agenda: 1. Caspian Services Inc., Group of Companies 2. Operational Highlights Marine Service Geophysical Services Marine Base Dr. Mirgali Kunayev, Chairman of the Board of Directors Alexey Kotov, CEO President Caspian Services…
CASPIAN SERVICES INC., GROUP OF KAZAKHSTAN COMPANIES Caspian Services Inc. PUBLICLY TRADED CORPORATION 100% 100% 100% Caspian Services Group Limited Caspian Geophysics Limited Caspian Real Estate Limited 100% 100% 80% 78%…
Caspian Services Inc History Set up in 1999 by Kazakhstani and USA nationals with marine services experience Became a US SEC registered issuer in 2002-2003 (stock CSSV) Acquired Tat-Arka and KazMorGeophysika On-shore and Off-shore…
Focused on providing marine and geophysical services in Kazakh portion of Caspian sea 5 Source: Caspian Services Inc. information
FROM OUR OPERATING HUB IN BAUTINO BAY 6 Source: Caspian Services Inc. information
Overview Key Figures Joint EBRD 28.6 million equity and debt Construction of a Marine Supply Base to support financing the offshore hydrocarbon developments in the - 10 million EBRD equity investment North Caspian - 18.6 million…
Atash Marine Base General marine services facilities Can accommodate rock transport Supports drilling activities: mud MOBY plants, cleaning of cuttings and associated transports Waste removal: Compliant with 70,000m2 available…
Marine service and rock transport fleets need port facilities like CSI marine base 9 Source: Caspian Services Inc. information
State-of-the-Art Marine Base Located Close to Major Offshore Field Development Oman Pearls Kashagan Kurmangazy Tengiz Computer Representation of CSIs Atash Marine Base on Bautino Bay Tyub-Karagan 10 Source: Caspian…
Offshore Marine Services Fleet Owned: 9 Shallow Draft Vessels Leased: 6 Shallow Draft Vessels 11 Source: Caspian Services Inc. information
Geophysical Services Same customer base as Marine Services Two basic types of projects Exploration Management Both onshore and offshore capability Strong customer base 12 Source: Caspian Services Inc. information
1. Geological and geophysical services Geological and Geophysical operations are carried out by: -Tat-Arka LLP -Kazmorgeophysica JSC - Veritas Caspian JV (50% of shares are owned by Kazmorgeophysica JSC)
Tat-Arka LLP Service geophysical surveying company
About the company The Company Tat-Arka has been established in 2001 in the Republic of Kazakhstan and actively operates in the sphere of service geophysical services rendering in Oil and Gas branch, carrying out 2D and 3D onshore…
Seismic station Our seismic crews are completed with seismic stations Sercel-408UL (France). The seismic station includes the floor equipment and the computerized operators position. Sercel 408UL is a standard system of seismic data…
Floor equipment Floor equipment includes: - Groups of geophones JF-20DX - Link - LAUL - LAUX - Power cable - Incross connection cable
Excitation source Using of non-explosive sources of elastic vibrations at seismic prospecting works allows to reduce time and material costs of works, and accordingly to reduce a cost of exploration works. Now seismic crews are…
Experience During industrial activity Tat-Arka LLP has executed in total seismic works 2D more than 10 000 l.km, and 3D 5000 sq. Km. The largest projects are: Koblandy and Bestau structure Bols CJSC, seismic works 2D 850 ln. km.…
Experience Koblandy area OilTechnoGroup LLP, seismic works 3D 690 sq. km. Kozhasai, Makhat vostochnyi depositions, KazakhoilEmba JSC, SW3D 210 sq.km. Bosoba deposit Munai LLP, seismic works 3D 230 sq. km. Zhubantam area EmbaYugNeft…
Kazmorgeophysica JSC Service geophysical surveying company
About company Kazmorgeophysica JSC has been created in 2002. The company is a resident of the Republic of Kazakhstan. The head office of Kazmorgeophusic is located in Almaty city. The company is engaged in carrying out of seismic…
Services Kazmorgeophysica renders the following complex of services within the Republic of Kazakhstan: Seismic works 2D and 3D on sea, shoal, transit zones as well as ashore Electric explorations by the method DNME Geochemical…
Equipment At carrying out of seismic works Kazmorgeophysica JSC uses the following equipment: Seismic station Sercel 428, 2007
Seismic station BOX (Fairfield), 2007
Pneumosources Malysh (Pulse JSC) for works on shoal and transit zones
For carrying out of works on sea the company has its own vessel vibration source Vessel for carrying out of bathymetry and navigation
At works in shoal zones shallow-water vessels are used
At works in transit zones vehicles with high flotation are used
Experience Atash area Atash LLP, seismic works 2D Atash area Atash LLP, electric explorations by the method DNME Tjub-Karagan area branch of Tjub-Karagan Operating Company B.V., electric explorations by the method DNME Kurmangazy…
Experience Shagala Block Veritas Caspian LLP, seismic works 2D Daytskaya area Profit LLP, seismic works by the method ANCHAR Dolinnoe Deposit Emir Oil LLP, seismic works by the method ANCHAR Aksai area BOLS LLP, seismic works by the…
2. Support of marine operations Caspian Services Group Limited 3. Infrastructure projects Balykshy LLP
2. Support of marine operations Caspian Services Group Limited
Caspian Services Group Limited renders full spectrum of marine trasport services. Caspian Services Group Ltd . operates own vessels and vessels of the Acta Marine company in Caspian Sea. Dutch company Acta Marine mainly works on…
Fleet CSGL. Residing vessels (flotel) Baskunchak Hotels on shoal provide residing of oil industry workers, as well as are used at carrying out of marine seismic works within shallow and transit zones. In addition barge…
Shallow Cargo vessels Shallow draft up to 2 meters and zero release of wastes Capacity up to 5000 -10000 tons
High speed vessels For today delivery of personnel for works on artificial islands is basically made by helicopters, which allows to transport only 8 persons and minimum quantity of cargo. Therefore, CSI company has designed and has…
Caspian Spider Barge for cable laving
Tows and survey vessels New vessels type MUCs CSGL has 2 survey vessels (tow vessels as well) Caspian Eva and Caspian Galiya
3. Infrastructure projects BalykshyLLP
Balykshy LLP The base of support of marine operations
Balykshy LLP The base of support of marine operations The marine base is located on east coast of Bautino gulf as far as 140 km. from regional center Aktau city. Bautino gulf forms natural harbor with a width about 1,8 km. The gulf…
Presentation of the project to the President of the Republic of Kazakhstan The base has been put in commissioning on July 1, 2010
Basic specification of the base of support of marine operations Area 12,74 Ha Length of harbor wall 552 m Dock decking reinforced concrete slab 11040 sq. m. Platform for crane with capacity of 200 thnd. tn. Landing dock for lifting of…
The base of support of marine operations The company provides the following services of marine base: Bunkering of diesel fuel Bunkering of potable and industrial water Cargo-handling operations, processing of floating cargoes…
The base of support of marine operations Competitive advantages The base of support of marine operations is constructed according to the high technologies and corresponds to all international standards (attestation of ISO…
Utilization Plan
Proposed Route for Conveyor from Quarry
Financial indicators of the CSI company for 2007 - 2009 Total Taxes Paid in Kazakhstan 62, 344, 634. 63 Name Caspian Services Inc. Marine Geophysics Infrastructure KAZAKHSTAN BUDGET TAXES PAID 26,569,421.97 28,787,847…
LOCAL CONTENT
Overall Customer Base 54 Source: Caspian Services Inc. information
Veritas Caspian is a joint venture between Veritas DGC (subsidiary enterprises of CGGVeritas Group) and Kazakhstan company Kazmorgeophysica. Veritas Caspian is a Limited Liability Partnership, has been established in August 2005,…
The Seismic data base of North Caspian, created for 2006 - 2009 Seismic works have been carried out within north-east part of Kazakhstan sector of Caspian sea. The depth of water was from 1.5 m up to 10 m. Today the total volume of…
Principles of non-exclusive seismic works (SPEC) The basic conditions of agreement on non-exclusive seismic exploration between VC and Ministry of Energy set forth below: Exclusive rights - VC has exclusive right for marine seismic…
Veritas Caspian Up to 2009 Program Proposed 2D up to 2011 Existing 2D
Seismic works Marine seismic works CMOC (Zhemchyuzhnaya site) CMOC Caspi Meruerty Operating Company Volume of works seismic survey 3D - 900 sq. Km.. The works have been successfully performed in 2008-2009 Forthcoming marine…
The Data Processing Center of Veritas-Caspian, has been opened in Almaty since March 2007. First of all the data processing in Veritas Caspian is intended for surveys, connected with works on data base in Caspian sea. The processing…
Computering center The computering center has been created considering further expansion of area and power input. The list of equipment: Binary cluster Core Opteron BladeRack 52 units, 64 bicyclic CP 275 Opteron Processing systems…
Reading of tapes from seismic records and its reformatting. The volume and type of tapes with seismic records have considerable chenges for last years. The Processing center Veritas Caspian has a possibility to read information…
CONTACT INFORMATION Corporate Office 2nd Floor, 134 Azerbayev Street district Zhana Kok-Tobe Almaty 050010 Republic of Kazakhstan Tel: +7 727 250 8477 or 8478 or 8480 Fax: +7 727 250 8479 Email: corporatesecretarycaspianservicesinc.com
CONTACT INFORMATION Marine Services Office 523, Zvezda Aktau Business Centre, block 61, 14 mcr Aktau 130000 Republic of Kazakhstan Tel: +7 729 247 0010 or 0011 or 0012 or 0013 Fax: +7 729 247 0014 Email: marinecaspianservicesinc.com
CONTACT INFORMATION Geophysics Services 134 Azerbayev Street Disctrict Zhana Kok-Tobe Almaty 050010, Republic of Kazakhstan Tel/Fax: +7 727 261 31 10 Email: geocaspianservicesinc.com
CONTACT INFORMATION Marine Infrastructure 2nd Floor, 134 Azerbayev Street District Zhana Kok-tobe, Almaty 050010 Republic of Kazakhstan Tel: +7 727 250 8477 or 8478 or 8480 Fax: +7 727 250 8479 Email: basecaspianservicesinc.com
