Gradiant Energy Services Water Management through Game-Changing technologies Julie Villalobos Vice President Sales & Marketing Enercom Conference Denver, CO 2017
Gradiant Energy Services Fundamentals 77 ENERCOM CONFERENCE DENVER, CO 2017 2
Gradiant Energy Services Fundamentals ENERCOM CONFERENCE DENVER, CO 2017 3
Our Fundamentals People EHS Record TRIR 0.0 in 2017 TRIR 0.8 over 3 years 1 recordable incident in company history HSE Award Recognition from Major Independent Fig 1. Industry Technology Recognition ENERCOM CONFERENCE…
Our Fundamentals Technology Application Gradiant Corporation Gradiant Energy Services Established out of Service Focused Massachusetts Institute of Technology (MIT) Safety Strong IP portfolio to handle DBOO Model toughest water…
Market Outlook More than 900,000 oil and gas wells in the United States 130,000 have been drilled since 2010 Completion Intensity on the rise Fewer Rigs, Far more Output SOURCE: EIA ENERCOM CONFERENCE DENVER, CO 2017 6
Technology & Efficiency Well Productivity & Cost Improvements Increased Water Increased Volume Lateral Length Increased Sand Volumes Water Demand in Permian Reduced Cluster Expected to Quadruple by 2026 Spacing Reduce…
Service Line Offering Bacteria Treatment Re-Usable Clean Brine Evaporative Disposal Desalination Bacteria/H2S/biofilm Patented clarifier Patented technology Patented technology Onsite generation Proprietary chemical Evaporative…
Free Radical Disinfection Water + Salt + Electricity Green and Safe Focus on Quality Control FRD Equipment Layout ENERCOM CONFERENCE DENVER, CO 2017 9
Case History Midland Basin 1,232,000 729 108, 564 Bbls of Water Treated Average ORP of Gallons of Oxidant Pumped Treated Water 432 6.9 3,153 Hrs. to Complete the Job Average ppm of FAC Bbls of Fresh Water Used ENERCOM…
Case History Delaware Basin 12 10 8 < 6 days 6 4 2 0 Average FAC (PPM) Per Day 1000 900 800 700 600 500 400 300 200 100 0 ORP Raw ORP Treated ENERCOM CONFERENCE DENVER, CO 2017 11
Quality Control 12
What is different. Traditional Floc and Drop System Selective Chemical Extraction Designed to handle varying water quality Specific Chemistry Plan Varying Chemical Dosages developed through Influent WQ algorithm Clarifier to manage…
Water Challenges Made Simple System is designed to have flexibility in changing chemistry and chemical type Continuous in-field chemistry testing to adjust to variability in influent produced water Gradiant Operations in WTX…
Case History Delaware Basin Purpose: Treat produced and flowback Total suspended solids (TSS), Iron, Oil and grease, Hydrogen sulfide & bacteria treatment Unique Challenge: Oil / Grease and TSS fluctuated as water was delivered…
The Challenges Issues with high inlet oil More than 3 tank batteries feeding the SWD Operator injecting chemicals intermittently : Biocides Turbidity O&G H2S…
Oil Control Process Primary OR VRU Clarifier OWS Process OIL CONTROL PROCESS PERFORMANCE 700 646.8 Effluent Influent 600 538.1546.3 500 445.5 0 & G CONC. (PPM) 403.7 393.4382.7 375.3368.5 383.2397.3371.4389.8 400…
Sludge Generation Oil Removed After GES Process ENERCOM CONFERENCE DENVER, CO 2017 18
Efficient Oil Removal Benefits Oil Recovery Lower chemical consumption Better Separation Reduced sludge generation Cleaner pit Meet KPIs Before and After GES ENERCOM CONFERENCE DENVER, CO 2017 19
Carrier Gas Concentrator - Applications Applications Exploratory areas lacking infrastructure Areas with high trucking costs Enhancing evaporation pond capacity Disposal constrained areas Products of System Atmospheric…
Carrier Gas Concentrator CGCTM Technology Mobile evaporation pit on NO CONTACT steroids BETWEEN COMBUSTION FLAME OR FLUE Patented humidification GASES AND PRODUCED process WATER TO BE EVAPORATED Multi-stage bubble column with…
Marcellus Case History Summary: Water Treatment Cost Estimations* 40000 35000 30000 25000 Volume (bbls) 20000 15000 10000 5000 0 Water Types Total Influent Total Evaporated Total Rejected *Doesnt include other…
Our Fundamentals - Economics 60+ patents in portfolio Value creating through true technology differentiation Full commercialization though service execution Design, Build, Own, Operate model for water treatment facilities Value…
Volume Under Management (VUM) Bacteria Disinfection Treatment Pipeline Selective Chemical Extraction Pipeline Hundred Thousand Treated (BPD) Volume in Millions of bbls treated MAR APRIL MAY JUNE JULY AUG SEPT OCT NOV DEC…
DE-RISKING THE PLATFORM CLIENT DIVERSIFICATION - H2 2018 ENERCOM CONFERENCE DENVER, CO 2017 26
